FY-TECH FY-9BX Dent Puller on Trolley for Automotive Panel Repair
Couldn't load pickup availability
FY-TECH FY-9BX Dent Puller on Trolley for Automotive Panel Repair
--------------------------------------------------------------
⚠️ CLICK & COLLECT ONLY⚠️
This product cannot be shipped. Please select Pickup in Store at checkout. Orders containing this item are not eligible for delivery.
--------------------------------------------------------------
The Fy-Tech FY-9BX Multi-Functional Dent Puller is a digitally controlled dent pulling and welding system designed for automotive panel beating and body repair. Supplied on a trolley, it provides a practical workshop solution for repairing damaged steel panels using a range of welding and pulling techniques.
Its microprocessor control system optimises welding parameters, allowing operators to select welding current according to the workpiece thickness. Automatic mains voltage monitoring, welding gun testing and overheat protection support consistent operation during repair work.
Suitable for conventional and stainless steel automotive panels, the FY-9BX supports multiple repair procedures, including washer welding, stud welding, shrinking, spot welding and direct dent pulling. The trolley-mounted design allows convenient movement and positioning around the workshop.
Key Features
- Multi-Functional Dent Repair: Supports dent pulling, shrinking, washer welding, stud welding and spot welding applications.
- Digital Microprocessor Control: Optimises welding parameters for different workpiece thicknesses.
- Trolley-Mounted Design: Provides a mobile workstation for automotive body repair operations.
- Built-In Monitoring and Protection: Features automatic mains voltage monitoring, welding gun testing and overheat protection.
- Steel Panel Compatibility: Suitable for repairing conventional steel and stainless steel automotive panels.
ADDITIONAL INFORMATION
- Brand: Fy-Tech
- Model / Product Code: FY-9BX
- Type: Digital Multi-Functional Dent Puller with Trolley
- Application: Automotive Dent Pulling, Panel Beating and Spot Welding
- Suitable Materials: Conventional Steel and Stainless Steel
- Input Voltage: 200V or 380V, 50/60Hz
- Maximum Rated Input Power: 12.3kVA
- Maximum Rated Input Current: 32A
- Maximum Output Current: 3500A
- Output Voltage: 1–13V
- Welding Time: 0–99 Seconds
- Dimensions: 930 x 350 x 830mm (Trolley); 220 x 350 x 250mm (Machine)
