| Air Inlet Thread |
1/2” BSP female |
| Regulated Outlets |
2 Valved |
| Unregulated Outlets |
N/A |
| Air Outlets (Ball Valves) |
1/ 4” BSP (M) |
| Width (Overall) |
395mm (15.5”) |
| Height (Overall) |
280mm (11”) |
| Weight |
4205 gms (165 oz) |
| Capacity (maximum air flow) |
900 l/min (32 cfm) |
| Maximum Air Inlet Pressure |
13 bar (189 psi) |
| Maximum Regulated Outlet Pressure |
0-8 bar (0-116 psi) |
| Maximum Operating Temperature |
80°C (176°F) |
| Pressure Gauge |
0-11 bar (0-160 psi) |
| Gauge port |
1/8” BSP (F) |
|
Degree of Filtration
(Output air quality class ISO8573-1)
|
1.7.1
(Down to 0.003 microns) |
| Drain Valve |
Semi-Automatic |
| Maximum Pressure Drop |
10% of Inlet Pressure |
